Dimensions
122.5 x 107.1 x 28 mm (4.8 x 4.2 x 1.1")
Port Layout


1 GbE RJ45
5 (4 PoE+; 1 PoE++) (1G/100M/10M)
Max. PoE Output
Up to PoE+
Total PoE Availability
46W
Form Factor
Compact desktop, wall, pole


Switching Capacity
10 Gbps
Total Non-Blocking Throughput
5 Gbps
Forwarding Rate
7 Mpps
Supported VLANs
1,000
MAC Address Table Size
2,000


Egress Rate Limit
Flow Control
Port Isolation
Port Mirroring
Jumbo Frames


PoE Ports


PoE+
4


PoE++
1
Max. PoE Wattage per Port by PSE


PoE+
25W
Max. Power Consumption
5W (Excluding PoE Output) 51W (Including PoE Output)
Power Method
PoE++
Power Input Method
PoE
Supported Voltage Range
50—57V PoE
Management
Ethernet
Heat Dissipation (Excluding PoE Output)
17.06 BTU/hr
Outdoor Ready
Weight
230 g (8.1 oz)
ESD Protection
Air/contact: ± 16kV
Ambient Operating Temperature
46W PoE output: -40 to 55° C (-40 to 131° F) 25W PoE output: -40 to 65° C (-40 to 149° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, Anatel


Application Requirements


UniFi Network
Version 5.10.3 and later
